INNOVATIVE AND DURABLE
Hydraulic Cylinders

HDM Cylinder Products

We can supply customers with many options and solutions to meet their precision hydraulic cylinder requirements, including welded hydraulic cylinders.

Depending upon the application, our engineers use the best of three materials: steel, stainless steel, and aluminum.

Products

Aluminum Hydraulic Cylinders

HDM is a leading manufacturer of aluminum hydraulic cylinders. These aluminum cylinders are durable, lightweight, and typically used in highly corrosive environments. Our aluminum hydraulic cylinders are rated to accommodate up to 3,000 PSI operating pressures.

Aluminum Hydraulic Cylinder

Double-Acting Hydraulic Cylinders

HDM custom designs and manufactures 1" to 5" bore double-acting hydraulic cylinders to meet the requirements of your application. Standard double-acting hydraulic cylinders accommodate operating pressures up to 3,000 PSI.

Double-Acting Hydraulic Cylinder

Piggyback Hydraulic Cylinders

Our piggyback hydraulic cylinders are designed to accommodate applications that require additional stroke and require consistent extension and retraction speed.

Piggyback Hydraulic Cylinder

Integrated Valves

Many cylinder designs have integrated valves, including counterbalance valves, pilot-operated check valves, sequencing valves, and thermal relief valves. HDM designs and manufactures hydraulic cylinders with integrated valves to meet the performance requirements of our customers' applications.

Integrated Hydraulic Cylinder

Rephase Hydraulic Cylinders

Our rephase hydraulic cylinders are designed to synchronize the extension and retraction of two or more cylinders. Custom rephrase cylinders are designed to meet the specific requirements of our customers' applications.

Rephase Hydraulic Cylinder

Linear Feedback Hydraulic Cylinders

Linear feedback devices can be internally or externally mounted to provide precise hydraulic cylinder positioning. Our customers use these cylinders for accurate positioning and velocity control of their system.

These hydraulic cylinders with linear feedback are custom designed to meet the specific requirements of our customers’ applications.

Linear Feedback Hydraulic Cylinder

Telescopic Hydraulic Cylinders

HDM is considered the industry leader in small-bore telescopic cylinders. We custom design our single-acting and double-acting telescopic cylinders to meet the requirements of your application.

Telescopic Hydraulic Cylinder

Ram Hydraulic Cylinders

HDM manufactures 1" to 3" solid rod rams and 3" to 5" hollow rod ram cylinders. HDM has various ram designs, including an adjustable v-packing design, a polypak rod seal design, and a heavy-duty design to accommodate side loading.

Ram Hydraulic Cylinder

Hydraulic Locking Cylinders

HDM designs and manufactures locking hydraulic cylinders for applications that require a hydraulic locking system. Our hydraulic locking features are uniquely integrated into the design of the cylinder.

Locking Hydraulic Cylinder

Custom Hydraulic Cylinders

Custom hydraulic cylinders by HDM are designed with the application in mind to avoid performance issues and increased costs, providing clear communication between engineers, suppliers, and manufacturers.

Custom Hydraulic Cylinders

Materials

  • Aluminum
  • Steel
  • Special Alloy Chrome Bar
  • Stainless Steel
  • Corrosion Resistant Coatings
  • Urethane Paint

Features

  • Cushioned Designs
  • ID & OD Threaded
  • Integrated Valves
  • Internal Ports
  • Linear Feedback
  • Low Friction
  • Low Friction Seals
  • Low Temperature Seals
  • Non-Rotating
  • Position Sensing

Contact Us

To learn more about how our innovative hydraulic cylinders are made with premium coatings and materials can deliver outstanding performance in highly corrosive environments, provide longer cylinders life, and decrease your maintenance costs, tell us who you are and briefly describe your application.

When you use HDM’s field-proven cylinders, you’re getting products and systems that are reliable, rugged and high-performance.
